Salient Features (Hatcher)
Low Power Consumption
Accurate
Easy to Maintain
Suitable for every water
For more % Hatchability
More Durable
Maintenance Free
Easy to Operate
220-250 vac
Fan Motor-1/3 HP (0.25 KW)
Turning Motor-1/2 HP (0.37 KW)
4 Heaters, each of 500 Watts (per compartment) Electrical requirement for a machine (For One Compartment) is approx. 2.5 KW for A Setter. When the Incubator (Setter or Hatcher has once acquired its working temperature, the electric requirement will be 1-2 KW per compartment / machine
Calibrated Thermometers of highest accuracy installed behind glass window for
reading Temperature and Humidity in the cabinet. Easily, without opening the doors.
Robust and Compact Reduction Gear Box driven by 1/2 HP Motor. The Electric Timer operates the Turning System Automatically Every Hour. The System is also povided with Stroke Counter which is fitted for Turning Counting.
Contact Thermometers operates automatically to control the
solenoid valve for regulating water flow for humidifier and cooling
system. Life long STAINLESS STEEL humidity guard provided.
Specially Designed Plastic Trays Are Provided For Easy Egg Setting and Extra Hatchability.
The Cabinet walls are made by Laminaed Panel, all Panels are Water Proof, Thermocol insulation with in, sturdy racks of thick iron painted with synthetic & with rust proofed bolts and nuts. Machine can be dismantled to facilitate their passages through a normal size door.
Control Panel provided, on front for quick accessability and to operate machine easily.
×
